Kiosks are operated by end customers. Quality and reliability are crucial. A good kiosk delivers a good user experience and establishes a good brand image.  We built our kiosks very seriously. Only high-quality components are used. The stability and the performance are guaranteed.

Demo Video

Self Ordering Kiosk


All components inside are well arranged for performance and reliability.
All cables are customized with the most suitable length.
Premium parts and components are used,
such as AUO LED panel and touch screen
 Strong stainless steel hinge
All cables are labelled for easy maintenance.
 Reinforced structure to ensure robustness.
Brackets can be customized to house
your selected payment devices.
Self Ordering Kiosk


Model name
KF-3220 (1) KF-3220 (2)
System Configuration
Intel® Core™ i3-6100TE Processor 4M Cache, 2.70 GHz
Intel® Core™ i5-6500TE Processor, 6M Cache, up to 3.3GMhz
Intel® Pentium® Processor G4400TE 3M Cache, 2.40 GHz
Intel® J1900 Processor 2M Cache, 2.00 GHz up to 2.42 GHz
System Memory DDR4 2133MHz SO-DIMM x 1,
Default 4G, Max. 8GB
DDR3L-1600Mhz SO-DIMM x 1,
Default 4G, Max 8GB
Storage Device SATA 2.5″ SSD (default 120G SSD), Option 2.5″ HDD
Power Supply DC12V/7.5A – 90W external power adapter. AC100 to 240V full range
O/S Support Win 10 PRO, Win 10 IoT, Win 7, POSReady 7
3″ Thermal Printer 3″ kiosk thermal printer, 260 mm/s, USB Interface
1D / 2D Scanner 2D: PDF417, MicroPDF417, Data Matrix, QR Code, MicroQR,
1D: UPC, EAN, Code 128, Code 39, Code 93, Code 11, Matrix 2 of 5,
Codabar, Interleaved 2 of 5, Mis Plessey, GSI DataBar, etc
Display & Touch
Display 21.5″, FHD
Touch Projected Capacitive Touch, Multi-Touch(10 Points), USB Interface
Physical & Environmental
(W*H*D mm)
1880*505*240mm(with stand)
1130*505 *184mm(without stand)
Weight 60kg (Body:41kg; Stand:19kg) approximately
Product Certification CE / FCC
Operation Temperature 0°C to 40°C
Storage Temperature -20°C to 70°C
MSR 2 or 3 Tracks, USB Interface
WiFi Mini PCI-E WiFi 802.11 a/b/g/n
Camera 2MP, USB Interface
RFID Reader By Customer
Fingerprint Scanner URU Fingerprint Scanner, USB Interface
Bracket Customized bracket for installing customer selected payment device (max. 2)
Click to download datasheet
Self Ordering Kiosk


Diverse Computing Options: Celeron, i3, i5, etc.

Card Readers: Swipe, Insert, Smart Card Readers

Printers: Receipt, Ticket, Card, Laser, Photo

Biometric Identity Scanners: Fingerprint, Iris Scanners, etc.

Bar Code Scanners: 1D, 2D, Custom

Document scanners: Passports, Visas, etc.

Cameras: Identity Profile Capture, Web Cameras

Wireless: 4G, BT, RFID, WiFi

Specialty Components: Solar Panels, UPS, etc.

Self Ordering Kiosk


Self Ordering Kiosk


With an experienced product design team, in-house manufacturing facilities, and a local support team, we ensure the success of your projects by providing you the best kiosk solutions in Vietnam in time and within your budget.
